MOTOROLA 2N1536 Transistor TO-3

( Brand: Motorola ), ( Manufacturer Part Number: 2N1536 )

Review MOTOROLA Transistor To-3

Motorola 2N1536 NPN Transistor: A Reliable Semiconductor Solution for Your Electronic Projects

The Motorola 2N1536 NPN Transistor is a versatile and high-quality semiconductor component, renowned for its reliability and performance in a wide range of electronic applications. This transistor is a part of Motorola's 2N series, which has been a trusted choice for engineers and hobbyists alike for decades.

The Motorola 2N1536 NPN Transistor is a small yet powerful device, designed to amplify or switch electronic signals. It is a three-terminal device, consisting of an emitter, base, and collector, and functions as a switch when a small current is applied to the base. The transistor's NPN (Negative-Positive-Negative) configuration makes it ideal for use in common-emitter, common-collector, and common-base amplifier circuits.

This transistor offers a maximum collector-emitter voltage (Vce) of 40V and a maximum collector current (Ic) of 800mA. With a minimum hFE (forward current gain) of 40 at room temperature, the Motorola 2N1536 ensures efficient signal amplification. The device also features a maximum power dissipation of 320mW, making it suitable for moderate power applications.

The Motorola 2N1536 NPN Transistor is housed in a TO-3 package, which provides excellent heat dissipation capabilities. The transistor's flat, circular base makes it easy to mount on a heat sink for optimal performance in high-power applications.

In summary, the Motorola 2N1536 NPN Transistor is a reliable and versatile semiconductor component, ideal for use in a wide range of electronic projects, from simple amplifier circuits to more complex power switch applications. Its TO-3 package ensures efficient heat dissipation, making it a suitable choice for both hobbyists and professional engineers.

Analysis of Motorola 2N1536 Transistor TO-3: Pros, Cons, and Recommendation

1. High Linear Power Handling: The Motorola 2N1536 transistor TO-3 offers excellent linear power handling, making it suitable for applications that require moderate power levels and low-frequency signals.

2. Wide Operating Voltage Range: This transistor can operate in a wide voltage range of 3V to 100V, providing flexibility in various circuit designs.

3. Good Availability: Motorola is a well-known and respected manufacturer, ensuring that the 2N1536 is readily available from numerous sources, both online and in physical electronics stores.

4. Robust Construction: The TO-3 package provides a good heat sink for the transistor, ensuring it can handle high power levels without overheating.

1. Limited Frequency Response: The Motorola 2N1536 is not designed for high-frequency applications, as its maximum usable frequency is relatively low.

2. Large Size: Compared to other transistor packages, the TO-3 package is quite large, which may pose challenges in compact circuit designs.

3. Higher Cost: While the 2N1536 is not excessively expensive, it may be slightly more costly compared to other transistors with similar specifications but smaller packages.

4. Limited Current Gain: The current gain of the 2N1536 is not as high as other NPN transistors, which might be a concern for certain applications that require high current amplification.

The Motorola 2N1536 transistor TO-3 is an excellent choice for applications that require moderate power handling, a wide operating voltage range, and a good heat sink. However, it may not be ideal for high-frequency applications, compact designs, or applications requiring high current gain.

If you're looking for a transistor for low-frequency, moderate power applications, and have the space for the larger TO-3 package, the Motorola 2N1536 could be a suitable option. However, if size is a concern or you need a transistor for high-frequency applications, you may want to consider alternative options with smaller packages and higher frequency response. Always ensure to carefully match the specifications of the transistor to your specific application requirements.

Details:

2N1536 TRANSISTOR TO-3.

part #: 2n1536 prices

• $24.81-$29.45

specifications electricalmiscoz:

• brand: Motorola
• mpn: 2n1536

returns electricalmiscoz:

• policy: No Returns

general electricalmiscoz:

• condition: Used
• Electrical Supplies > Electrical Wire Cable Accessories > Electrical Wire Cable Connectors

shipping electricalmiscoz:

• class: Standard
• type: Fixed
• cost: $5.75
• transit: 3-8 Days
• carrier: USPS
• service: USPS Ground Advantage

payments electricalmiscoz:

• credit card: Mastercard
• wallet: Google-pay
• other

offer electricalmiscoz:

• started: July 7, 2025
• quantity: 6
• options: Ship-to-home
• sold: 0
• availability: In Stock
• best offers: True

seller electricalmiscoz:

• # reviews: 983
• city: Teaneck, New Jersey
• rating: 97.4%
